| Operating voltage: | 3.6~5VDC | Average current: | < 85 mA |
|---|---|---|---|
| Measurement range: | Selectable within 0~10% Vol range | Interface level: | 3.0V |
| Output signal: | UART 0.4-2V | Preheating time: | 3 min |
| إبراز: | infrared CO2 gas sensor,carbon dioxide detection probe,MH-411D CO2 concentration sensor,carbon dioxide detection probe,MH-411D CO2 concentration sensor |
||
Product Description:
YJJ MH-411D Infrared Carbon Dioxide Gas Sensor CO2 Concentration Detection Sensor Probe
Features:
MH-411D carbon dioxide gas sensor is a universal and intelligent infrared gas sensor (hereinafter referred to as the sensor). This sensor uses the non-dispersive infrared (NDIR) principle to detect the C02 present in the air. The sensor is oxygen-independent, has stable performance and a long lifespan. It is equipped with internal temperature compensation. This sensor is a small-sized high-performance sensor made by closely integrating mature infrared absorption gas detection technology with micro-machining and excellent circuit design.
Application fields
Indoor air quality monitoring
HVAC and refrigeration
Industrial process and safety protection monitoring, agricultural and livestock production process monitoring
Gas detection: Carbon Dioxide
Operating voltage: 3.6~5VDC (requires safety barrier power supply)
Average current: < 85 mA
Measurement range: Selectable within 0~10% Vol range
Interface level: 3.0V
Output signal: UART 0.4-2V
Preheating time: 3 min
Response time: To < 30 S
Operating temperature: -20~60 ℃
Operating humidity: 0~95%RH (no condensation)
Dimensions: 20 mm x 22.2 mm
Weight: 35 g
Life span: 5 years
Protection level: IP54
Specifications:
| Minimum Operating Temperature | -25 °C |
| Maximum Operating Temperature | +85 °C |
| Response time | To < 30 S |
| Accuracy | 5% |
